Product Details

Refrigerated truck

  • Category : Faw-Trucks
  • Sub Category : Special Vehicles
  • SKU : Refrigerated truck

FAW Refrigerated Truck: Freshness Delivered with Precision. Built on the reliable FAW Truck chassis with efficient WEICHAI/YUCHAI engines (130-190HP), it ensures temperature-controlled transport for perishable goods. Multiple wheelbase options (3300-5250mm) provide excellent maneuverability for urban and regional deliveries. The insulated body maintains consistent temperatures for optimal product quality. FAW. Your Trusted Partner in Cold Chain Logistics.

Product Details

Product Details

Refrigeration performance

The refrigeration system of the export refrigerated trucks is advanced, capable of precisely controlling the temperature. It can be flexibly adjusted from -20°C to 8°C to meet the storage needs of various goods.

Thermal insulation performance

The enclosure is made of high-quality insulation materials, providing excellent insulation effect. It effectively reduces heat loss and lowers energy consumption.

Safety performance

Equipped with multiple safety protection devices, such as temperature monitoring and alarm systems, to ensure the safety of goods during transportation.

Configuration Category Specific parameters and descriptions
Basic structure and materials
  1. Inner and outer skin of the compartment: high-quality fiberglass sheet;
  2. Internal insulation material: high-performance polyurethane;
  3. Sheet thickness: 105mm for top and bottom panels, 85mm for side panels;
  4. Floor panel: high-strength polyurethane composite board, hand-laid fiberglass on all four sides (waterproof).
Size Specifications
  1. Internal dimensions of the box: 6800mm×2430mm×2500mm or customized;
  2. External dimensions of the box: conform to the announcement standards to ensure the compliance of the whole vehicle.
Structural components
  1. Edge edging and locks: Aluminum alloy edge edging, stainless steel locks and rear door frame hinges, lock anti-collision beam;
  2. Additional components: 1 side door, 1 toolbox, 1 stainless steel ladder;
  3. Connections and protection: Buffer blocks, aluminum side guardrails, rear bumper painted red and white.
Lighting and drainage systems
  1. Lighting: Four ceiling lights, all complete, with switches installed at the top of the container;
  2. Drainage: One 2-inch drain outlet (with PPC valve) on each side of the rear end of the container, plus a stainless steel drainage channel.
Safety and Signage
  1. Protective devices: mudguards, full vehicle splash guard;
  2. Markings and markings: reflective panels on the body, printed vehicle identification number (VIN);
  3. Auxiliary accessories: stainless steel drainage channel.
Product Type FRF refrigerated truck
truck Refrigerated truck
